Function to plot simple 2D graphics for univariate effects/functions.

```
plot2d(x, residuals = FALSE, rug = FALSE, jitter = TRUE,
col.residuals = NULL, col.lines = NULL, col.polygons = NULL,
col.rug = NULL, c.select = NULL, fill.select = NULL,
data = NULL, sep = "", month = NULL, year = NULL,
step = 12, shift = NULL, trans = NULL,
scheme = 2, s2.col = NULL, grid = 50, ...)
```

- x
A matrix or data frame, containing the covariate for which the effect should be plotted in the first column and at least a second column containing the effect. Another possibility is to specify the plot via a

`formula`

, e.g.`y ~ x`

, see the examples.`x`

may also be a character file path to the data to be used for plotting.- residuals
If set to

`TRUE`

, residuals may also be plotted if available. Residuals must be supplied as an`attr`

ibute named`"residuals"`

, which is a matrix or data frame where the first column is the covariate and the second column the residuals.- rug
Add a

`rug`

to the plot.- jitter
- col.residuals
The color of the partial residuals.

- col.lines
The color of the lines.

- col.polygons
Specify the background color of polygons, if

`x`

has at least 3 columns, i.e. column 2 and 3 can form one polygon.- col.rug
Specify the color of the rug representation.

- c.select
Integer vector of maximum length of columns of

`x`

, selects the columns of the resulting data matrix that should be used for plotting. E.g. if`x`

has 5 columns, then`c.select = c(1, 2, 5)`

will select column 1, 2 and 5 for plotting. Note that first element of`c.select`

should always be the column that holds the variable for the x-axis.- fill.select
Integer vector, select pairwise the columns of the resulting data matrix that should form one polygon with a certain background color specified in argument

`col`

. E.g.`x`

has three columns, or is specified with formula`f1 + f2 ~ x`

, then setting`fill.select = c(0, 1, 1)`

will draw a polygon with`f1`

and`f2`

as boundaries. If`x`

has five columns or the formula is e.g.`f1 + f2 + f3 + f4 ~ x`

, then setting`fill.select = c(0, 1, 1, 2, 2)`

, the pairs`f1`

,`f2`

and`f3`

,`f4`

are selected to form two polygons.- data
If

`x`

is a formula, a`data.frame`

or`list`

. By default the variables are taken from`environment(x)`

: typically the environment from which`plot2d`

is called. Note that`data`

may also be a character file path to the data.- sep
The field separator character when

`x`

or`data`

is a character, see function`read.table`

.- month, year, step
Provide specific annotation for plotting estimation results for temporal variables.

`month`

and`year`

define the minimum time point whereas step specifies the type of temporal data with`step = 4`

,`step = 2`

and`step = 1`

corresponding to quarterly, half yearly and yearly data.- shift
Numeric constant to be added to the smooth before plotting.

- trans
Function to be applied to the smooth before plotting, e.g., to transform the plot to the response scale.

- scheme
Sets the plotting scheme for polygons, possible values are

`1`

and`2`

.- s2.col
The color for the second plotting scheme.

- grid
Integer, specifies the number of polygons for the second plotting scheme.

- ...
Other graphical parameters, please see the details.

For 2D plots the following graphical parameters may be specified additionally:

`cex`

: Specify the size of partial residuals,`lty`

: The line type for each column that is plotted, e.g.`lty = c(1, 2)`

,`lwd`

: The line width for each column that is plotted, e.g.`lwd = c(1, 2)`

,`poly.lty`

: The line type to be used for the polygons,`poly.lwd`

: The line width to be used for the polygons,`density`

`angle`

,`border`

: See`polygon`

,`...`

: Other graphical parameters, see function`plot`

.

```
## Generate some data.
set.seed(111)
n <- 500
## Regressor.
d <- data.frame(x = runif(n, -3, 3))
## Response.
d$y <- with(d, 10 + sin(x) + rnorm(n, sd = 0.6))
if (FALSE) ## Estimate model.
b <- bamlss(y ~ s(x), data = d)
summary(b)
#> Error in summary(b): object 'b' not found
## Plot estimated effect.
plot(b)
#> Error in h(simpleError(msg, call)): error in evaluating the argument 'x' in selecting a method for function 'plot': object 'b' not found
plot(b, rug = FALSE)
#> Error in h(simpleError(msg, call)): error in evaluating the argument 'x' in selecting a method for function 'plot': object 'b' not found
## Extract fitted values.
f <- fitted(b, model = "mu", term = "s(x)")
#> Error in fitted(b, model = "mu", term = "s(x)"): object 'b' not found
f <- cbind(d["x"], f)
#> Error in data.frame(..., check.names = FALSE): object 'f' not found
## Now use plot2d.
plot2d(f)
#> Error in plot2d(f): object 'f' not found
plot2d(f, fill.select = c(0, 1, 0, 1))
#> Error in plot2d(f, fill.select = c(0, 1, 0, 1)): object 'f' not found
plot2d(f, fill.select = c(0, 1, 0, 1), lty = c(2, 1, 2))
#> Error in plot2d(f, fill.select = c(0, 1, 0, 1), lty = c(2, 1, 2)): object 'f' not found
plot2d(f, fill.select = c(0, 1, 0, 1), lty = c(2, 1, 2),
scheme = 2)
#> Error in plot2d(f, fill.select = c(0, 1, 0, 1), lty = c(2, 1, 2), scheme = 2): object 'f' not found
## Variations.
plot2d(sin(x) ~ x, data = d)
d$f <- with(d, sin(d$x))
plot2d(f ~ x, data = d)
d$f1 <- with(d, f + 0.1)
d$f2 <- with(d, f - 0.1)
plot2d(f1 + f2 ~ x, data = d)
plot2d(f1 + f2 ~ x, data = d, fill.select = c(0, 1, 1), lty = 0)
plot2d(f1 + f2 ~ x, data = d, fill.select = c(0, 1, 1), lty = 0,
density = 20, poly.lty = 1, poly.lwd = 2)
plot2d(f1 + f + f2 ~ x, data = d, fill.select = c(0, 1, 0, 1),
lty = c(0, 1, 0), density = 20, poly.lty = 1, poly.lwd = 2)
```
